TG8ELT
Technical Information
Material | Height | Information | ||
Top Cover | Nylon | Plastic | 14.4mm | ID 28.8mm |
Compression ring | Nylon | Plastic | 6.5mm | ID 28.6mm |
Top Cone | SS41 | Steel | 5.3mm | ID 30.0mm |
Upper Stationary Cup | SS41 | Steel | 15.4mm | Insertion 34.0 +0.1 -0/ 8mm depth |
Lower Stationary Cup | SS41 | Steel | 15.4mm | Insertion 34.0 +0.1 -0/ 8mm depth |
Crown Cone | SS41 | Steel | 9.0mm | Insertion 30.0 +0 -0.1 |
Lower Seal Ring | Nylon | Plastic | 4.7mm | |
Ball Retainer x 2 | Chorome Balls | Steel | #800 | 5/32"x 22 Balls |
