Technoglide 1.5CB
Ride Large
Lightweight and strong duraluminum alloy construction
OnePointFive size for the Most Extreme riders.
Tange Seiki specially designed 1.5” cartridge bearings.
Fully Sealed Mechanism
Technical Information
| Material | Height | Information | ||
| Top Cover | A6061-T6 | Light Alloy | 5.2mm | ID 38.2mm |
| Compression ring | A6061-T6 | Light Alloy | 6.0mm | ID 38.1mm |
| Upper Stationary Cup | A6061-T6 | Light Alloy | 25.5mm | Insertion 49.65 +0.1 -0/ 12.5 depth |
| Lower Stationary Cup | A6061-T6 | Light Alloy | 25.5mm | Insertion 49.65 +0.1 -0/ 12.5 depth |
| Crown Cone | SS41 | Steel | 4.8mm | Insertion 39.74mm +- 0.25 |
| Cartridge Bearing x 2 | SUJ2 | Steel | 8.0mm | OD 52mm/ ID 40mm #1728 |
| Lower Seal Ring | Nylon | Plastic | 0.5mm |
